日立零件查询（AR2000）BURNER PIPING (MX) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
504 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | Y971050 | [2] | TUBE | |
| 01. | Y971051 | [1] | TUBE | |
| 02. | Y409805 | [1] | PIPE | |
| 03. | Y971053 | [1] | TUBE LINE | |
| 04. | Y700815 | [1] | TUBE LINE | |
| 05. | Y801760 | [1] | HANGER | |
| 06. | Y301446 | [1] | BRACKET | |
| 07. | Y409679 | [6] | BOLT;U | |
| 08. | Y409680 | [1] | BOLT;U | |
| 11. | Y301451 | [1] | WASHER | |
| 12. | Y409681 | [2] | WASHER | |
| 13. | Y409688 | [1] | PLUG | |
| 14. | Y301455 | [1] | SHIELD | |
| 16. | Y410180 | [1] | TUBE | |
| 17. | 4221469 | [1] | HOSE;RUBBER | |
| 18. | 4420354 | [2] | CLAMP;HOSE | |
| 19. | Y410344 | [1] | HOSE;AIR | |
| 20. | J901245 | [8] | BOLT | |
| 21. | J950012 | [8] | NUT | |
| 22. | A590912 | [8] | WASHER;SPRING | |
| 23. | J931845 | [8] | BOLT | |
| 24. | J950018 | [8] | NUT | |
| 25. | J257218 | [8] | WASHER;SPRING | |
| 26. | J950008 | [14] | NUT | |
| 27. | A590908 | [21] | WASHER;SPRING | |
| 28. | M450832 | [4] | SCREW;SET | |
| 29. | Y410817 | [1] | GAS;PROPANE | |
| 2901. | +++++++ | [1] | GAS BOMB | |
| 2902. | +++++++ | [1] | REGULATOR | |
| 2903. | +++++++ | [1] | HOSE | |
| 2904. | +++++++ | [1] | FITTING;HOSE | |
| 2905. | +++++++ | [2] | BAND | |
| 30. | 4053594 | [2] | CLAMP | |
| 31. | 4154651 | [3] | ADAPTER;S | |
| 32. | 4154656 | [2] | ELBOW;S | |
| 34. | 4156433 | [2] | ELBOW | |
| 36. | 4215649 | [1] | ADAPTER;S | |
| 37. | 4221278 | [4] | ADAPTER;S | |
| 38. | 4221287 | [13] | ADAPTER;S | |
| 39. | 4345723 | [4] | ADAPTER;S | |
| 40. | 4351271 | [3] | ADAPTER;S | |
| 41. | 94-0615 | [1] | ELBOW;S | |
| 42. | 94-0617 | [1] | ELBOW;S | |
| 44. | 94-0632 | [1] | ELBOW;S | |
| 45. | 94-0633 | [2] | ELBOW;S | |
| 46. | 94-0660 | [1] | TEE | |
| 47. | 94-0662 | [5] | TEE;S | |
| 49. | 94-0677 | [2] | SOCKET;S | |
| 50. | 94-0678 | [1] | SOCKET | |
| 52. | 94-1602 | [2] | REDUCER | |
| 53. | 94-1608 | [2] | REDUCER | |
| 54. | 94-1703 | [4] | ADAPTER;S | |
| 55. | 94-1704 | [2] | ADAPTER;S | |
| 56. | 94-1903 | [3] | ADAPTER;S | |
| 57. | 94-2024 | [1] | PLUG | |
| 58. | A590910 | [8] | WASHER;SPRING | |
| 59. | J901045 | [8] | BOLT | |
| 60. | Y407662 | [2] | ADAPTER;S | |
| 61. | Y410343 | [1] | ELBOW;S | |
| 62. | Y410404 | [1] | HOSE ASS'Y | |
| 6200. | +++++++ | [1] | HOSE | EE-07-19-065N(1･1/16-12UN) |
| 6201. | +++++++ | [1] | HOSE | EG-21-12-070N(3/4-16UNF) |
| 6202. | +++++++ | [1] | HOSE | GG-21-12-050N(3/4-16UNF) |
| 6203. | +++++++ | [1] | HOSE | EE-03-12-070N(3/4-16UNF) |
| 6204. | +++++++ | [1] | HOSE | EG-03-12-080N(3/4-16UNF) |
| 6205. | +++++++ | [1] | HOSE | EG-03-19-075N(1･1/16-12UN) |
| 6206. | +++++++ | [1] | HOSE | EE-21-06-095N(7/16-20UNF) |
| 6207. | +++++++ | [1] | HOSE | EG-07-06-110S(7/16-20UNF) |
| 6208. | +++++++ | [1] | HOSE | EE-07-06-700S(7/16-20UNF) |
| 6209. | +++++++ | [1] | HOSE | EE-21-06-115N(7/16-20UNF) |
| 6210. | +++++++ | [1] | HOSE | GG-21-12-095N(3/4-16UNF) |
| 6211. | +++++++ | [1] | HOSE | EG-21-12-120N(3/4-16UNF) |
| 6212. | +++++++ | [1] | HOSE | EE-21-12-120N(3/4-16UNF) |
| 63. | Y971169 | [1] | COVER | |
| 65. | Y410715 | [1] | UNION | |
| 68. | Y410688 | [1] | COUPLING | |
| 69. | Y971204 | [1] | PIPE;FLANGE | |
| 80. | 94-1701 | [1] | ADAPTER;S | |
| 81. | 4053593 | [3] | CLAMP;PIPE | |
| 82. | 4190271 | [3] | CLIP | |
| 83. | J900812 | [7] | BOLT | |
| 84. | J900825 | [4] | BOLT | |
| 92. | 94-0631 | [1] | ELBOW;S | |
| 94. | Y410681 | [1] | COUPLER | |
| 95. | Y402305 | [1] | FITTING;HOSE | |
| 96. | 4514700 | [2] | CLIP;HOSE | |
| 97. | Y410690 | [1] | HOSE | |
| 98. | Y410682 | [1] | REEL;HOSE | |
| 99. | Y410676 | [1] | HOSE | |
| 100. | 94-1702 | [1] | ADAPTER;S | |
| 101. | Y402910 | [1] | FITTING;HOSE | |
| 102. | Y410683 | [1] | GUN | |
| 103. | J901060 | [4] | BOLT | |
| 106. | 4190125 | [4] | CLAMP;PIPE | |
