| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1(B). | 8944537371 | [1] | FILTER ASM; FUEL | |
| 2. | 8944537382 | [1] | ELEMENT KIT; FUEL FILTER | |
| 8. | 5132120700 | [1] | COVER; FUEL FILTER | |
| 8. | 5132120700 | [1] | COVER; FUEL FILTER | |
| 10. | 1132600470 | [1] | VALVE; OVERFLOW,FUEL FILTER | |
| 10. | 1132600470 | [1] | VALVE; OVERFLOW,FUEL FILTER | |
| 30. | 1096300850 | [2] | GASKET; OVERFLOW VLV | |
| 40(A). | 5197550010 | [1] | BRACKET; FUEL FILTER | |
| 45. | 0501410350 | [2] | BOLT; FUEL FILTER | M10X35W/LK&PL WASHER |
| 45. | 0286810300 | [2] | BOLT; FUEL FILTER | M10X30 FLANGE |
| 54. | 1094680021 | [1] | NUT; CAP,OVERFLOW VLV | |
| 69(A). | 9099063141 | [1] | BOLT; EYE,FUEL FILTER | |
| 69(B). | 9099063251 | [2] | BOLT; EYE,FUEL FILTER | |
| 88. | 0500410200 | [2] | BOLT; BRKT,FUEL FILTER | M10X20 W/LK WASHER |
| 88. | 0500410200 | [2] | BOLT; BRKT,FUEL FILTER | M10X20 W/LK WASHER |
| 88. | 0280810200 | [2] | BOLT; BRKT,FUEL FILTER | M10X20 FLANGE |
