纽荷兰零件查询(DC150PS) - CRAWLER DOZER (1.266[05]) - REAR TRANSMISSION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
770 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76073042 | [1] | CLUTCH DISC | LECCLUTCH DISK - LEFT |
| 1. | 76073043 | [1] | CLUTCH DISC | LECCLUTCH DISK - RIGHT |
| 2. | 76072203 | [2] | BOX | LEC |
| 3. | 11076976 | [2] | SNAP RING,M140, Int | TTF |
| 4. | 11070876 | [2] | CIRCLIP,M80, Ext | TTF85 80 Superseded by part number: 80370009 |
| 5. | 76072102 | [4] | BEARING,80mm ID x 140mm OD x 26mm W | LEC Superseded by part number: 87562149 |
| 6. | 76072174 | [2] | SPACER | LEC- BEARING |
| 7. | 76072172 | [2] | SPACER | LEC- BEARING |
| 8. | 9824642 | [24] | BOLT,M12 x 1.75 x 42.68mm, Cl 10.9 | BHB Superseded by part number: 626-12035 |
| 9. | 14496731 | [24] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 10. | 14496631 | [16] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 11. | 11106231 | [16] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 12. | 14469980 | [2] | O-RING,14.984" ID x 15.262" OD x 0.139" | LEC(M380.6 ID x 3.53 Thk) Superseded by part number: 70926561 |
