| 1. |
86639836
|
[1] |
COVER
|
NH
|
| 2. |
86634558
|
[1] |
SUPPORT ASSY.
|
NH
RH
|
| 3. |
86619277
|
[1] |
SHIELD
|
NH
|
| 4. |
86634529
|
[1] |
SPACER
|
NH
|
| 5. |
86628307
|
[1] |
FILLER
|
NH
RH
|
| 6. |
121202
|
[1] |
CHAIN
|
NH
RC50, 79 Pitches, Includes: (1) Offset & (1) 25194 Connector Link Superseded by part number: 1791DX
|
| 7. |
86603075
|
[4] |
FLANGE,Bearing, 52.01 mm ID x 95.3 mm OD x 8.7 mm
|
NH
Bearing
|
| 8. |
204807C91
|
[2] |
BEARING ASSY,25.4mm ID x 52mm OD x 15mm W
|
CAS
|
| 9. |
86636650
|
[1] |
DRIVEN SPROCKET
|
NH
17T
|
| 10. |
825-1408
|
[6] |
NUT,M8, Cl 8
|
CAS
Superseded by part number: 43362
|
| 11. |
811-8030
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
|
| 12. |
455102R21
|
[2] |
COLLAR
|
IH
Superseded by part number: 47577183
|
| 13. |
825-5148
|
[3] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 14. |
811-8020
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 15. |
86637289
|
[1] |
AUGER
|
NH
RH
|
| 16. |
86628576
|
[1] |
KEY
|
NH
1/4" Sq., x 1-1/4"
|
| 17. |
285072
|
[3] |
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
|
NH
(3/8")
|
| 18. |
381014
|
[4] |
SCREW,Flng, M8 x 16mm
|
NH
HWH, M8 x 1.25 x 16
|
| 19. |
25194
|
[1] |
CONNECTING LINK
|
GI
RC50, Spring Clip Type Superseded by part number: 86537460
|
| 20. |
9800957
|
[3] |
WASHER,35.81mm ID x 50.8mm OD x 1.52mm Thk
|
NH
|
| 21. |
86637251
|
[1] |
DRIVEN SPROCKET
|
NH
44T
|
| 22. |
121602
|
[1] |
BALL BEARING,28.6mm Hex x 72mm OD x 37.7mm W
|
NH
|
| 23. |
86620026
|
[2] |
FLANGED BEARING
|
NH
|
| 24. |
905-10020
|
[3] |
BOLT,Hex Flg, M10 x 20mm
|
CAS
Superseded by part number: 274249
|
| 25. |
825-51410
|
[6] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 26. |
829-1412
|
[1] |
NUT,M12, Cl 10.9
|
CAS
Superseded by part number: 337475
|
| 27. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 28. |
86514717
|
[1] |
IDLER WHEEL
|
NH
Eccentric, Nylon
|
| 29. |
814-12060
|
[1] |
BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 9706693
|
| 30. |
811-10020
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86512422
|
| 31. |
733-5040
|
[1] |
COTTER PIN,M5 x 40
|
CAS
Superseded by part number: 130011
|
| 32. |
29684
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
17/32" ID x 2" OD x 3/16" Thk
|
| 34. |
87028747
|
[1] |
PLUG
|
PA
Plastic, for 1" Dia. Hole
|
| 35. |
905-10025
|
[3] |
BOLT,Hex Flg, M10 x 25mm
|
CAS
Superseded by part number: 274251
|
