| 1. |
86542445
|
[1] |
SUPPORT
|
NH
|
| 3. |
9848489
|
[1] |
BEARING ASSY,73 mm ID x 132.1976 mm OD x 38.10 mm, Round Bore
|
NH
Includes: Ref. 5 Superseded by part number: 47531138
|
| 4. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 5. |
8050825
|
[1] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 6. |
86574943
|
[1] |
ROLLER
|
NH
Drive, Includes: Ref. 5 Superseded by part number: 87028612
|
| 7. |
9801709
|
[1] |
FLANGE,106 mm ID x 154.5 mm OD x 46.5 mm
|
NH
Includes: Ref. 4
|
| 8. |
9808110
|
[2] |
WASHER,46mm ID x 60mm OD x 1.64mm Thk
|
NH
Hardened, M45
|
| 9. |
87032323
|
[1] |
SPROCKET
|
PA
Half & Sprocket, 22T
|
| 10. |
100-11162
|
[1] |
SNAP RING,#162, Ext
|
CAS
Superseded by part number: 45440
|
| 11. |
87028608
|
[1] |
CLUTCH
|
NH
Half
|
| 12. |
86640119
|
[1] |
SPRING,Compression, 2.438" OD x 4.5" L
|
NH
|
| 13. |
9829364
|
[1] |
CAP COVER
|
NH
|
| 14. |
9849862
|
[1] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
NH
HH, Drilled, G5, 1/2"-13 x 1-1/2"
|
| 15. |
811-10030
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 16. |
825-1410
|
[2] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 17. |
219-36
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF
|
CAS
Superseded by part number: 80717
|
| 18. |
86538519
|
[1] |
PLATE
|
NH
|
| 19. |
614-10020
|
[6] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 21. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 22. |
145788
|
[4] |
WASHER,10.32mm ID x 22.23mm OD x 3.5mm Thk
|
NH
Hardened, 3/8"
|
