| 1. |
86637278
|
[1] |
ROLLER
|
NH
Starter
|
| 2. |
86636760
|
[2] |
RING
|
NH
|
| 3. |
86636675
|
[1] |
WASHER,40mm ID x 51.2mm OD x 4mm Thk
|
NH
Radiused
|
| 4. |
196010
|
[1] |
SHIM,.036" Thk
|
NH
|
| 5. |
274247
|
[4] |
BOLT,Hex Flg, M10 x 16mm, Stainless
|
NH
|
| 6. |
86620027
|
[4] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 7. |
664073R92
|
[2] |
BALL BEARING,38.1mm ID x 80mm OD x 21mm W
|
CAS
|
| 8. |
455112R11
|
[2] |
COLLAR
|
IH
Includes: Setscrew Superseded by part number: 47577185
|
| 9. |
614-12030
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 10. |
492-11056
|
[4] |
LOCK WASHER,9/16"
|
CAS
Superseded by part number: 80280248
|
| 11. |
829-1412
|
[2] |
NUT,M12, Cl 10.9
|
CAS
Superseded by part number: 337475
|
| 12. |
86637256
|
[1] |
DRIVING SPROCKET
|
NH
|
| 13. |
714379
|
[2] |
CLUTCH
|
NH
Jaw Superseded by part number: 87639816
|
| 14. |
86637392
|
[1] |
DRIVEN SPROCKET
|
NH
20T, Includes Ref. 31
|
| 15. |
263422
|
[1] |
WASHER,53.18mm ID x 90.42mm OD x 1.52mm Thk
|
NH
|
| 16. |
166490
|
[1] |
WASHER,51.6mm ID x 76.2mm OD x 3.68mm Thk
|
NH
2", Heat Treated
|
| 17. |
9822385
|
[6] |
BELLEVILLE WASHER,52mm ID x 100mm OD x 3.3mm Thk
|
NH
|
| 18. |
86637290
|
[1] |
SEALING RING COLLAR
|
NH
|
| 19. |
281042
|
[1] |
SLOTTED NUT,1"-8
|
NH
G2 Superseded by part number: 87343900
|
| 20. |
432-1224
|
[1] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
Superseded by part number: 80754
|
| 21. |
66849
|
[1] |
WASHER,51.59mm ID x 76.2mm OD x 3.17mm Thk
|
NH
Nylon, 2"
|
| 22. |
86637257
|
[1] |
HUB
|
NH
|
| 24. |
54055
|
[3] |
SPACER
|
NH
|
| 25. |
86637253
|
[1] |
SUPPORT
|
NH
|
| 26. |
694478
|
[1] |
WASHER,13.5mm ID x 57.15mm OD x 4.8mm Thk
|
NH
1/2", Heat Treated
|
| 27. |
86637244
|
[1] |
DRIVEN SPROCKET
|
NH
22T
|
| 28. |
86637167
|
[2] |
WASHER,61.2mm ID x 71.8mm OD x 2.7mm Thk
|
NH
2-13/16" OD, Heat Treated
|
| 29. |
814-10040
|
[1] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 120112
|
| . . |
492-11044
|
[1] |
LOCK WASHER,7/16"
|
CAS
Superseded by part number: 81547
|
| 30. |
814-12070
|
[3] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
IH
Superseded by part number: 9706717
|
| 31. |
46962
|
[1] |
BUSHING,2" ID x 2.13" OD x 1.25" L
|
NH
|
| 32. |
126-47
|
[1] |
WOODRUFF KEY,#28, 5/16" x 2 1/8"
|
CAS
Superseded by part number: 87123
|
| 34. |
26312
|
[1] |
WASHER
|
NH
1-1/2" OD Superseded by part number: 695335
|
| 35. |
86514717
|
[1] |
IDLER WHEEL
|
NH
|
| 36. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 37. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 39. |
86611730
|
[1] |
WASHER,38.9mm ID x 60.3mm OD x 3.68mm Thk
|
NH
2-3/8" OD
|
| 40. |
25494
|
[1] |
WASHER,38.9mm ID x 50.8mm OD x 1.5mm Thk
|
NH
2" OD
|
