纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (2.346[02]) - TRACK IDLER - SUPPORT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
917 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79032029 | [1] | SUPPORT | LEC- RIGHT |
| 2. | 79032030 | [1] | SUPPORT | LEC- LEFT |
| 3. | 4989877 | [2] | PLATE | LEC- INNER |
| 4. | 4989878 | [2] | PLATE | LEC- OUTER |
| 5. | 4989879 | [1] | SHIM | LEC |
| 6. | 587020 | [1] | PLATE | LEC |
| 7. | 587089 | [12] | SCREW,Hex, M16 x 1.5 x 35mm, Cl 8.8 | LEC |
| 8. | 587019 | [4] | GUIDE | LEC |
| 9. | 79032032 | [4] | SLIDING PAD | LEC |
| 10. | 79031906 | [8] | SCREW | LEC |
| 11. | 16105021 | [8] | LOCK NUT,M12 x 1.25, Cl 10 | TTF |
| 12. | 12605971 | [12] | WASHER | LEC16,3X25,5 Superseded by part number: 12605979 |
| 13. | 14257834 | [12] | BOLT,Hex, M16 x 1.5 x 35mm, Cl 10.9, Full Thd | LEC |
