纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.665[02]) - AIR CONDITIONING - CONDENSER - OPTIONAL CODE 76066319 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
550 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76052520 | [1] | CONDENSER | LEC- ASSY SEE PAG.7, Serial Range: -C3933 Superseded by part number: 76067510 |
| 1. | 76067510 | [1] | CONDENSER | LEC, Start Serial: D3933 |
| 2. | 76066221 | [1] | WIRE HARNESS | LEC |
| 3. | 76067365 | [1] | HOSE | LEC |
| 4. | 76067366 | [1] | HOSE | LEC |
| 5. | 76067364 | [1] | SUPPORT | LEC Superseded by part number: 76067608 |
| 6. | 76067404 | [4] | TIE-ROD | LEC |
| 7. | 76067378 | [1] | SHIM | LEC |
| 8. | 79109011 | [4] | PAD | LEC- LOWER |
| 9. | 79109014 | [4] | PAD | LEC- UPPER |
| 10. | 11107231 | [4] | SCREW,Hex, M10 x 50mm, Cl 10.9 | LEC Superseded by part number: 75205092, 43249 |
| 11. | 14496631 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 12. | 12577221 | [4] | LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 10, ZND | LEC |
| 13. | 76067405 | [1] | RUBBER WASHER | LEC |
| 14. | 76067714 | [1] | RUBBER WASHER | LEC |
| 15. | 76067367 | [1] | GUARD | LEC |
| 16. | 16043031 | [2] | BOLT,Hex, M8 x 12mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43231 |
| 17. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 18. | 71405770 | [1] | CLAMP,25mm ID, 15mm Bolt Hole, P Type | LEC Superseded by part number: 84551318 |
| 19. | 14496901 | [1] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: |
| 19. | 14497131 | [1] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
