凯斯零件查询(RBX561) - CASE IH ROUND BALER (12/01-8/02) (008) - PICKUP TIRE & WHEEL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
238 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86620655
|
[2] |
SUPPORT
|
NH
|
| . . |
829-1412
|
[4] |
NUT,M12, Cl 10.9
|
CAS
Superseded by part number: 337475
|
| . . |
811-12040
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 328754
|
| . . |
433-828
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
Superseded by part number: 88530
|
| 2. |
86634544
|
[2] |
SEALING RING COLLAR
|
NH
|
| 4. |
86616348
|
[2] |
WHEEL
|
NH
|
| 5. |
136376
|
[2] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
Oil
|
| 6. |
572564R1
|
[4] |
BEARING CUP
|
IH
Superseded by part number: 132709
|
| 7. |
D29266
|
[4] |
ROLLER BEARING,1" ID x 0.58"
|
CAS
Superseded by part number: 132710
|
| 8. |
26301
|
[2] |
WASHER
|
NH
Special
|
| 9. |
603373
|
[2] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Jam, G2, 1"-14 Superseded by part number: 143183
|
| 10. |
432-1220
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Superseded by part number: 87398
|
| 11. |
200734
|
[2] |
HUB CAP
|
NH
|
| 12. |
25447
|
[2] |
TIRE TUBE
|
NH
Inner, 4.00 - 8
|
| 13. |
136378
|
[2] |
TYRE/TIRE
|
NH
4.80/4.00 x 8, 4 Ply, Tubeless
|
| . . |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| . . |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
