纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (02-05) - COOLANT RECOVERY SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
385 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | A171099 | [3] | HOSE CLAMP,13.2mm - 15.4mm | CAS |
| 2. | 433737A1 | [1] | HOSE,7.90 mm ID x 725.00 mm, SAE J30 or SAE 20R4 Class D1 | BURCut From L126767; Radiator to Coolant Reservoir |
| 3. | L127093 | [1] | RESERVOIR | CAS |
| 4. | A184079 | [1] | CAP | CAS Superseded by part number: 440729A1 |
| 5. | 905-8020 | [4] | BOLT,Hex Flg, M8 x 20mm | CASM8 x 20 Superseded by part number: 86511479 |
| 6. | 832-4748 | [4] | FLANGE NUT,M8 x 1.25, Flg, Cl 8 | CAS Superseded by part number: 86050303 |
| 7. | 433784A1 | [1] | HOSE,7.90 mm ID x 445.00 mm, SAE J30 or SAE 20R4 Class D1 | BURCut From L126767, Overflow |
| 8. | 515-23143 | [3] | CLAMP,9/16", Insul, 3/8" Bolt | CAS Superseded by part number: 72187280, 257492 |
| 9. | 827-10045 | [1] | BOLT,Hex, M10 x 1.5 x 45mm, Cl 10.9 | CAS Superseded by part number: 86508618 |
| 10. | 39519 | [3] | WASHER,10.31mm ID x 34.9mm OD x 3.57mm Thk | CASWasher Under Clamp May Be Replaced With Loctite 243 On Some Models |
| 11. | 309096A1 | [1] | SQUARE NUT | CASM10 Superseded by part number: 229197A1 |
| 12. | 336371A1 | [1] | PIN | CAS |
