纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (02-07) - AIR CLEANER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
572 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87434701 | [1] | AIR CLEANER | BURIncl. Ref 1 - 7 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing |
| 2. | 82981152 | [1] | AIR FILTER | MEXPrimary Superseded by part number: 84217229 |
| 3. | 82981153 | [1] | AIR FILTER | MEXSecondary Superseded by part number: 87682999 |
| 4. | 395792A1 | [1] | COVER ASSY | CAS Superseded by part number: 47132327 |
| 5. | A184597 | [1] | VALVE POPPET,1.93" ID x 2.24" OD x 1.84" L | CASRubber |
| 6. | 79081900 | [1] | SENSOR | LECAir |
| 7. | 217-194 | [1] | FITTING,1/8"-27 NPTF, Brass | CAS1/8 x 1/8, Brass Superseded by part number: 87014030 |
