凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (2-32) - ROLLER DRIVE ASSEMBLY, LOWER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1006 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
654437R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - roller, #80 (10 Foot Bulk)
|
| 2. |
241-1418
|
[1] |
SPRING CLIP
|
CAS
LINK - connector, #80 R/C
|
| 3. |
7086002
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - roller, #60 (10 Foot Bulk) Superseded by part number: 611362R91X, 241-1316
|
| 4. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
LINK - connector, #60 R/C
|
| 5. |
61747
|
[2] |
KEY
|
CAS
1/2 X 2-1/2 GIB KEY
|
| 6. |
700150109
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - double, 23 and 36 tooth
|
| 7. |
326-1256
|
[1] |
BOLT,Hex, 3/4" - 10 x 3-1/2", Gr 8
|
CAS
|
| 8. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 9. |
95-81182
|
[2] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
3/4 X 14 GAUGE NRMB
|
| 10. |
747931
|
[1] |
DECAL
|
CAS
SPROCKET - idler, 12 tooth Superseded by part number: 51200277, 51200277, NLS
|
| 11. |
6834071
|
[1] |
BUSHING
|
CAS
SPACER
|
| 12. |
700150105
|
[1] |
SPECIAL BOLT
|
HFI
DRAWBOLT WA
|
| 13. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 14. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 15. |
700135548
|
[1] |
SPECIAL BOLT
|
HFI
DRAWBOLT WA
|
| 16. |
700150114
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 25 tooth
|
| 17. |
700110610
|
[1] |
SPACER
|
CAS
|
| 18. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
- idler, 15 tooth
|
| 19. |
413-1048
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
Superseded by part number: 87338
|
| 20. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
