凯斯零件查询(RS551) - CASE IH ROUND BALER (1/99-12/00) (7-14) - SHIELD SUPPORT AND HINGE ASSEMBLIES, LEFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
362 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700135682
|
[1] |
SUPPORT
|
HFI
- L
|
| 2. |
7883325
|
[14] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
|
| 3. |
704239
|
[18] |
FRONT AXLE
|
NNA
5/16-18 HFSLN Superseded by part number: 231-5145, 231-5145, NLS
|
| 4. |
7883374
|
[12] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 255918
|
| 5. |
704734
|
[20] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
700135679
|
[1] |
SHIELD
|
HFI
- L
|
| 7. |
7700461
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 X 3/4 RHSSNB Superseded by part number: 280497
|
| 8. |
700702916
|
[2] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 9. |
700150824
|
[1] |
SHIELD
|
HFI
- L Superseded by part number: 700155631
|
| 10. |
700718401
|
[1] |
SHIELD
|
CAS
- rubber
|
| 11. |
700150883
|
[1] |
SHIELD
|
HFI
- lower, L
|
| 12. |
7700065
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 13. |
7883382
|
[8] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 X 1 HWHMS Superseded by part number: 87034804
|
| 14. |
700150220
|
[1] |
SUPPORT
|
HFI
- L
|
| 15. |
700707701
|
[4] |
HINGE
|
CAS
- butt
|
| 16. |
700135628
|
[2] |
SUPPORT
|
HFI
|
| 17. |
700135684
|
[1] |
SUPPORT
|
HFI
- L
|
| 18. |
700132505
|
[1] |
SUPPORT
|
HFI
- valve, mount
|
| 19. |
700135634
|
[1] |
SUPPORT
|
HFI
|
