| 1. |
515-25127
|
[1] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Line Superseded by part number: 86632595
|
| 2. |
515-2395
|
[5] |
CLAMP,3/8", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 86572009
|
| 3. |
700718506
|
[1] |
CLIP
|
CAS
plastic, barbed
|
| 4. |
700716058
|
[1] |
HARNESS
|
CAS
wire, kicker (without mesh wrap)
|
| 5. |
700716828
|
[1] |
RELAY
|
CAS
electrical
|
| 6. |
700718448
|
[1] |
GASKET
|
CAS
relay
|
| 7. |
440-1088
|
[2] |
SCREW,Cross Pan Hd, #8-32 x 1/2"
|
CAS
Superseded by part number: 81822758
|
| 8. |
495-21019
|
[2] |
WASHER,#8
|
CAS
Superseded by part number: 280299, 72187261
|
| 9. |
492-11008
|
[2] |
LOCK WASHER,#8
|
CAS
Superseded by part number: 87812
|
| 10. |
225-14108
|
[2] |
NUT,#8-32
|
CAS
hex, GR. 2 #8-32 Superseded by part number: 86977693
|
| 11. |
281-34912
|
[7] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
hex washer head thread cutting tapping, 3/8-16 x 3/4
|
| 12. |
409-7612
|
[1] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 13. |
232-5316
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 14. |
700710188
|
[7] |
SCREW
|
CAS
cross recess pan head machine, #6-32 x 3/4 (stainless)
|
| 15. |
700710187
|
[8] |
WASHER
|
CAS
plain, special, #6
|
| 16. |
700710189
|
[7] |
LOCK NUT
|
CAS
light hex stop, #6-32 (stainless)
|
| 17. |
700710199
|
[6] |
GROMMET
|
CAS
|
| 18. |
700709996
|
[1] |
SWITCH
|
IH
ACTUATOR
|
| 19. |
700718012
|
[1] |
SWITCH
|
CAS
ASSEMBLY (N.C.)
|
| 20. |
702400102
|
[1] |
CONDUIT
|
CAS
split
|
| 21. |
121-3
|
[2] |
SERRATED BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
|
CAS
|
| 22. |
700150915
|
[1] |
SHIELD
|
HFI
|
| 23. |
700119161
|
[1] |
SWITCH
|
L
ASSEMBLY (N.O.)
|
| 24. |
700150916
|
[1] |
MOUNTING PARTS
|
HFI
switch
|
| 25. |
700710211
|
[1] |
ACTUATOR
|
IH
ACTUATOR
|
| 26. |
700135943
|
[1] |
MOUNTING PARTS
|
HFI
ACTUATOR
|
| 27. |
700710208
|
[2] |
ROTARY SWITCH
|
L
(N.O.)
|
| 28. |
7883275
|
[1] |
SCREW,Hex Washer, 1/4" - 20 x 3/4"
|
CAS
hex washer head machine, 1/4-20 x 3/4
|
| 29. |
1703354
|
[1] |
NUT
|
IH
hex flange top lock, 1/4-20 GR/G
|
| 31. |
515-2179
|
[2] |
CLAMP,5/16", Insul, 1/4" Bolt
|
CAS
Line Superseded by part number: 237910
|
