斗山零件查询BRAKE - FRONT AXLE MEGA 400-V (CHINA) Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
899 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
K9002154
|
[1] |
KIT;SINTER DISC
|
|
| 2. |
K9002156
|
[1] |
KIT;SELF ADJUSTER(SINTER DISC)
|
|
| 10. |
K9000290
|
[2] |
PISTON
|
|
| 100. |
K9001887
|
[16] |
DISC;I.CLUTCH
|
|
| 110. |
K9001888
|
[18] |
DISC;O.CLUTCH
|
|
| 112. |
K9000327
|
[4] |
DISC;O.CLUTCH A=2.0
|
|
| 120. |
K9000717
|
[12] |
PIN
|
|
| 130. |
K9000172
|
[48] |
RING;GRIPPING
|
|
| 140. |
K9000175
|
[84] |
SPRING;CUP
|
|
| 150. |
K9000289
|
[2] |
SHIM;SUPPORT
|
|
| 160. |
K9000169
|
[12] |
RING;SNAP
|
|
| 170. |
K9000170
|
[2] |
RING;SNAP
|
|
| 180. |
K9000031
|
[12] |
PIN;SLOT
|
|
| 20. |
K9000243
|
[2] |
U-RING
|
|
| 30. |
K9000241
|
[2] |
RING;SUPPORT
|
|
| 50. |
K9000244
|
[2] |
U-RING
|
|
| 60. |
K9000242
|
[2] |
RING;SUPPORT
|
|
| 70. |
K9000168
|
[2] |
RING;GUIDE
|
|
