凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (2-016) - CLUTCH MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
159 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700719452
|
[1] |
UNION
|
HFI
rotary
|
| 2. |
700719436
|
[6] |
BOLT
|
HFI
3/8" x 1 1/2", hex. socket head shoulder screw, SPL
|
| 3. |
700719451
|
[1] |
CYLINDER ASSY.
|
HFI
hydraulic, includes: REF.15
|
| 4. |
700719432
|
[1] |
CLUTCH ASSEMBLY
|
HFI
|
| 5. |
483-1386
|
[1] |
SET SCREW,Hex Soc, 3/8"-16 x 3/8"
|
CAS
3/8"-16 x 3/8", cup point hex. socket set, NP Superseded by part number: 86624120
|
| 6. |
61481
|
[1] |
KEY
|
HFI
3/8" x 1 1/4" Superseded by part number: 061481
|
| 7. |
483-13812
|
[1] |
SET SCREW,Hex Soc, 3/8"-16 x 3/4"
|
CAS
3/8"-16 x 3/4", cup point hex. socket set, NP
|
| 8. |
52712
|
[2] |
BUSHING
|
CAS
1 1/2" x 18, narrow rim machinery, GA
|
| 9. |
700719447
|
[2] |
BEARING, NEEDLE
|
HFI
1.500, Bore
|
| 10. |
700132730
|
[1] |
SPROCKET ASSY.
|
HFI
WA
|
| 11. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 12. |
413-616
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 13. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 14. |
700132584
|
[1] |
BUSHING
|
HFI
|
| 15. |
700719686
|
[1] |
SEAL KIT
|
HFI
KIT
|
