纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.522[03]) - RIPPER (PD) - TOOL BAR - OPTIONAL CODE 76030342 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
686 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79098882 | [2] | PIN | LEC |
| 2. | 79029322 | [5] | PLATE | LEC |
| 3. | 13407211 | [5] | LUBE NIPPLE,M10 x 1 | TTF Superseded by part number: 84351730 |
| 4. | 79029435 | [6] | RING | LEC |
| 5. | 11108031 | [6] | BOLT,Hex, M10 x 90mm, Cl 10.9 | LEC Superseded by part number: 86508620 |
| 6. | 12577221 | [6] | LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 10, ZND | LEC10X1,5X12,3 |
| 7. | 76004253 | [3] | PIN | LEC |
| 8. | 11106231 | [10] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 9. | 14496631 | [10] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 10. | 79102870 | [1] | ARM | LEC |
| 11. | 79098884 | [1] | PIN | LEC |
| 12. | 79098880 | [2] | PIN | LEC |
