纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6520[009]) - ROPS CAB-COVERING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
210 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79095604 | [1] | METAL LINER | LECCOVERING - ASSEMBLY RIGHT |
| 1. | 79095606 | [1] | METAL LINER | LECCOVERING - ASSEMBLY LEFT |
| 2. | 79095576 | [1] | METAL LINER | LECCOVERING - ASSEMBLY LEFT |
| 2. | 79095585 | [1] | METAL LINER | LECCOVERING - ASSEMBLY RIGHT |
| 3. | 79087844 | [1] | DIFFUSER | LEC |
| 4. | 13296311 | [2] | SCREW | LEC3x0,5x14 |
| 7. | 79095960 | [1] | COVER | LEC |
| 8. | 79095582 | [1] | SOFT TRIM | LECCOVERING - RIGHT |
| 8. | 79095592 | [1] | METAL LINER | LECCOVERING - LEFT |
| 9. | 79095596 | [1] | METAL LINER | LECCOVERING - RIGHT |
| 9. | 79095602 | [1] | METAL LINER | LECCOVERING - LEFT |
| 10. | 79086145 | [1] | CONTAINER | LEC |
| 10. | 79086146 | [1] | CONTAINER | LEC |
| 11. | 79087456 | [1] | METAL LINER | LECCOVERING |
| 12. | 4417913 | [1] | CONTAINER | BUR |
| 13. | 79031824 | [2] | HANDLE | LECCOAT-HOOK |
| 14. | 79045197 | [1] | ASH TRAY | LECASHTRAY Superseded by part number: 76043643 |
| 15. | 13313417 | [2] | SCREW,Pozidriv Oval Hd, Csk, M6 x 25mm, Cl 5.8, Full Thd | IMO |
| 16. | 79076208 | [13] | WASHER | LEC |
| 17. | 13313217 | [48] | SCREW,Pozidriv Oval Hd, Csk, M6 x 20mm, Cl 5.8, Full Thd | LEC |
| 18. | 79089592 | [37] | WASHER | IMO |
| 19. | 15902707 | [4] | SELF-TAP SCREW,Cross Pan Hd, M3.5 x 19mm | BASSCREW |
| 20. | 79099417 | [1] | PLATE | LECD2703 |
| 21. | 13309217 | [2] | SCREW,Pozidriv Oval Hd, Csk, M4 x 16mm, Cl 5.8, Full Thd | LECD2703 Superseded by part number: 13309211 |
| 22. | 79076795 | [2] | SPRING | LECFASTENER D2703 |
