纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6520[010]) - ROPS CAB-COVERING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
860 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79083910 | [1] | ROOF | LECPANEL |
| 2. | 79095811 | [2] | ANGLE | LEC Superseded by part number: 79101828 |
| 3. | 79073493 | [1] | CAPPING | LECANGLE |
| 4. | 79095847 | [1] | METAL LINER | LECCOVERING |
| 5. | 79095527 | [1] | MAT | LEC Superseded by part number: 79104615 |
| 6. | 79089392 | [2] | BRACKET | LEC |
| 7. | 79094459 | [1] | CURTAIN | LEC |
| 8. | 14150290 | [2] | BULB,24V, 10W | MKT |
| 8. | 79095874 | [1] | GUIDE | LEC- LEFT |
| 8. | 79095875 | [1] | GUIDE | LEC- RIGHT |
| 9. | 79089257 | [1] | SUPPORT | LEC |
| 10. | 79067876 | [1] | CEILING LAMP | LECCEILING LIGHT Superseded by part number: 79103273 |
| 11. | 76008003 | [1] | REAR VIEW MIRROR | LEC |
| 11. | 79051015 | [1] | BULB | LEC Superseded by part number: 14142490 |
| 12. | 79076208 | [11] | WASHER | LEC |
| 13. | 13313417 | [11] | SCREW,Pozidriv Oval Hd, Csk, M6 x 25mm, Cl 5.8, Full Thd | IMO |
| 14. | 79076795 | [3] | SPRING | LECFASTENER |
| 15. | 13272417 | [3] | SCREW,Pozidriv Pan Hd, M4 x 20mm, Cl 5.8, Full Thd | BAS4x20 Superseded by part number: 86511826 |
| 16. | 13273921 | [2] | SCREW,Pozidriv Pan Hd, M5 x 10mm, Cl 8.8, Full Thd | LEC Superseded by part number: 13273924 |
| 17. | 13311217 | [6] | SCREW,Pozidriv Oval Hd, Csk, M5 x 20mm, Cl 5.8, Full Thd | IMO |
| 18. | 14496301 | [3] | WASHER,5.3mm ID x 10mm OD x 1mm Thk | BASM5.3 x 10 x 1 Thk Superseded by part number: 17094504 |
| 19. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC8,15x17 Superseded by part number: 86624184 |
| 20. | 16043231 | [2] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LECSCREW 8x1,25x16 |
