| 1. |
111-360
|
[1] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 2. |
496-11041
|
[1] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 3. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 4. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 5. |
700709945
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 1352.00 mm, SAE 100R2
|
CAS
(Includes item 6) 12.70 mm ID x 1352.00 mm, SAE 100R2
|
| 6. |
237-6010
|
[3] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
10-1, 90 Duro, .755" ID x .097" Thk Superseded by part number: 72186125, 167269
|
| 7. |
217-390
|
[1] |
FITTING,1" Hose Barb x 1-1/16" - 12 Male ORB
|
CAS
INSERT - hose (Includes item 8)
|
| 8. |
738484
|
[1] |
O-RING
|
IH
Superseded by part number: 167266
|
| 9. |
700709946
|
[1] |
HOSE
|
CAS
- hydraulic, suction
|
| 10. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 11. |
700121512
|
[1] |
SUPPORT
|
CAS
- tank, front
|
| 12. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 13. |
231-5146
|
[4] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 14. |
214-1420
|
[2] |
HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm
|
CAS
CLAMP, HOSE, #20, 0.81/1.75 Type F Worm Superseded by part number: 507586
|
| 15. |
700121513
|
[1] |
SUPPORT
|
CAS
- tank, rear
|
| 16. |
515-23238
|
[1] |
CLAMP,15/16", Insul, 3/8" Bolt
|
CAS
Hose 15/16", Insul, 3/8" Bolt Superseded by part number: 87029955
|
| 17. |
827717
|
[1] |
GROMMET
|
CAS
- rubber
|
| 18. |
700121573
|
[2] |
BEARING LINER
|
CAS
LINER - reservoir
|
| 19. |
700709759
|
[1] |
RESERVOIR ASSY.
|
CAS
RESERVOIR - oil
|
| 20. |
700709944
|
[2] |
STRAP
|
CAS
- reservoir
|
| 21. |
201021C1
|
[1] |
ELEMENT
|
IH
FILTER - oil
|
| 22. |
742643
|
[1] |
FILTER
|
CAS
ASSEMBLY (Includes item 21)
|
| 23. |
113-12
|
[2] |
BOLT,Hex, 1/4" - 20 x 2-1/2", Gr 5
|
CAS
1/4-20 X 2-1/2 C Superseded by part number: 87845
|
| 24. |
496-11028
|
[3] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 25. |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 26. |
425-104
|
[2] |
NUT,1/4"-20, Cl 5
|
CAS
Superseded by part number: 7770, 72187220
|
| 27. |
217-1073
|
[1] |
HYD CONNECTOR,3/4" - 14 NPTF
|
CAS
NIPPLE - male
|
| 28. |
7846124
|
[1] |
TEE
|
CAS
- swivel
|
| 29. |
432-48
|
[1] |
COTTER PIN,1/16" x 1/2"
|
CAS
PIN, SPLIT (COTTER), 1/16" x 1/2" Superseded by part number: 280236, 72187234
|
| 30. |
700124207
|
[1] |
ARM
|
CAS
- control
|
| 31. |
700709943
|
[1] |
ADAPTER
|
CAS
- male (Includes item 6)
|
| 32. |
218-5121
|
[1] |
ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 7/8" - 14 Male ORB
|
CAS
(Includes item 6) 90º, 3/4"-16, 37º x 7/8"-14, O-Ring Superseded by part number: 9617891
|
| 33. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 34. |
700121571
|
[1] |
SUPPORT
|
CAS
ANGLE - support, valve
|
| 35. |
700121572
|
[1] |
SUPPORT
|
CAS
- plate, valve
|
| 36. |
218-5137
|
[1] |
ELBOW,45 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB
|
CAS
Superseded by part number: 72186185, 330345
|
| 37. |
7796394
|
[1] |
VALVE
|
CAS
- flow control
|
| 38. |
700124210
|
[1] |
BRACKET
|
CAS
MOUNTING - valve
|
| 39. |
700706418
|
[1] |
CAP
|
CAS
DIP STICK - breather cap
|
