凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (9-42) - HYDRAULIC FLOW CONTROL VALVE ASSEMBLY (7796394 FLOW CONTROL VALVE ASSEMBLY COMPLETE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
420 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
7796394
|
[1] |
VALVE
|
CAS
FLOW CONTROL VALVE COMPLETE
|
| 1. |
8733313
|
[1] |
SPRING
|
CAS
- metering
|
| 2. |
8733354
|
[1] |
PLUG
|
CAS
- slotted
|
| 3. |
738484
|
[2] |
O-RING
|
IH
Superseded by part number: 167266
|
| 4. |
8733305
|
[2] |
PLUG
|
CAS
- main bore
|
| 5. |
8733297
|
[1] |
CAP
|
CAS
|
| 6. |
8733347
|
[1] |
ADJUSTMENT SCREW
|
CAS
- adjusting
|
| 7. |
8733289
|
[2] |
WASHER
|
CAS
- aluminum
|
| 8. |
425-1512
|
[1] |
JAM NUT,Jam, 3/4"-10, G5
|
IH
3/6-16 HEX JAM NUT Superseded by part number: 219758
|
| 9. |
8733321
|
[1] |
SPRING
|
CAS
- relief
|
| 10. |
211-1016
|
[1] |
BALL,12.7mm OD, Gr 24
|
CAS
Steel 1/2" Dia
|
| 11. |
38-11216
|
[2] |
LOCK PIN,3/16" x 1", Slotted
|
CAS
PIN, 3/16" x 1", Slotted Superseded by part number: 118827
|
| 12. |
8733370
|
[2] |
BACK-UP RING
|
CAS
RING - back up
|
| 13. |
700708088
|
[2] |
O-RING
|
CAS
|
| 14. |
103-1193
|
[2] |
SNAP RING,#93, Ext
|
CAS
Ring, Snap, #93, Ext
|
| 15. |
700704950
|
[1] |
THUMB SCREW
|
CAS
10-32 SCREW - thumb
|
| 16. |
700704948
|
[1] |
HANDLE
|
CAS
|
| 17. |
700704949
|
[1] |
KNOB
|
CAS
|
