| 1. |
515-23254
|
[4] |
CLAMP,1", Insul, 3/8" Bolt
|
CAS
Hose 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
|
| 2. |
700706425
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 3. |
4097612
|
[4] |
3/8-16 X 3/4 HFSS
|
|
| 4. |
231-5146
|
[7] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 5. |
7721798
|
[2] |
CABLE
|
CAS
TIE - cable
|
| 6. |
700110306
|
[1] |
SUPPORT
|
CAS
- shield, left
|
| 7. |
58180
|
[1] |
SPRING
|
CAS
- tension
|
| 8. |
6501167
|
[1] |
BOLT
|
CAS
3/8-16 DRAWBOLT
|
| 9. |
51200834
|
[1] |
BELT
|
CAS
V-BELT
|
| 10. |
425-106
|
[13] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 11. |
700111565
|
[1] |
SHIELD
|
CAS
- drive
|
| 12. |
256873
|
[2] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 13. |
409-7512
|
[5] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 14. |
231-5145
|
[5] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 15. |
700110550
|
[1] |
SUPPORT
|
CAS
- shield, right
|
| 16. |
154273C1
|
[4] |
BOLT,Hex Serr, 3/8" - 16 x 1", Spcl
|
IH
3/8-16 X 1 HFSS Superseded by part number: 9706726
|
| 17. |
496-11041
|
[9] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 18. |
492-11038
|
[11] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 19. |
515-23238
|
[4] |
CLAMP,15/16", Insul, 3/8" Bolt
|
CAS
Hose 15/16", Insul, 3/8" Bolt Superseded by part number: 87029955
|
| 20. |
111-360
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 21. |
738484
|
[2] |
O-RING
|
IH
Superseded by part number: 167266
|
| 22. |
218-5120
|
[2] |
ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB
|
CAS
90 DEGREE ELBOW (Includes item 21) Superseded by part number: 87329785
|
| 23. |
218-845
|
[1] |
TEE,37 Degree, 3/4"-16 x 3/4"-16, Fem Sw Run
|
CAS
Superseded by part number: 86511870, 72186150
|
| 24. |
700706426
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 25. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 26. |
7796386
|
[1] |
HYDRAULIC MOTOR
|
HFI
MOTOR - hydraulic Superseded by part number: 86629586, 700723556, 700723563, 76350
|
| 27. |
218-755
|
[2] |
CAP,37 Degree, 3/4"-16
|
CAS
(Shipping dust cap) 37º, 3/4"-16 Superseded by part number: 262159
|
| 28. |
433-620
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 29. |
230-4216
|
[1] |
LOCK NUT,3/8"-16, GA
|
CAS
3/8-16 HCLN Superseded by part number: 87039402
|
| 30. |
451641
|
[1] |
CLAMP
|
CAS
- line
|
| 31. |
700709942
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 2600.00 mm, SAE 100R2
|
CAS
12.70 mm ID x 2600.00 mm, SAE 100R2
|
| 32. |
700709941
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 2600.00 mm, SAE 100R1
|
CAS
12.70 mm ID x 2600.00 mm, SAE 100R1
|
| 33. |
1661172
|
[1] |
SUPPORT
|
CAS
SPADE - SMV
|
| 34. |
B17284
|
[1] |
CLEVIS PIN
|
IH
PIN - clevis, special
|
| 35. |
S120261
|
[2] |
PIN
|
CAS
.148 X 2-3/4 HAIRPIN COTTER
|
| 36. |
218-1054
|
[2] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 1/2"-14, NPTF
|
CAS
3/8 X 90 DEGREE ELBOW
|
| 37. |
700711032
|
[1] |
CYLINDER ASSY.
|
L
CYLINDER - hydraulic
|
| 38. |
700112726
|
[1] |
SUPPORT
|
CAS
BRACKET - mounting, cylinder
|
| 39. |
700711078
|
[1] |
PIN
|
CAS
1 X 3-7/32 CLEVIS PIN, special
|
| 40. |
434-616
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
