凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (9-46) - BALE THROWER HYDRAULIC DRIVE CYLINDER ASSY (796102 HYDRAULIC DRIVE CYLINDER ASSEMBLY COMPLETE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
311 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
796102
|
[1] |
CYLINDER
|
CAS
HYDRAULIC CYLINDER COMPLETE Superseded by part number: 700711032, 700711078
|
| 1. |
7733033
|
[1] |
CYLINDER
|
HFI
BARREL
|
| 2. |
230-46112
|
[1] |
LOCK NUT,3/4"-16, GA
|
CAS
LOCKNUT
|
| 3. |
H347757
|
[1] |
PISTON
|
CAS
|
| 4. |
7733041
|
[1] |
ROD
|
CAS
- piston
|
| 5. |
7733025
|
[6] |
GLAND
|
CAS
RETAINER (Gland)
|
| . . |
7733066
|
[1] |
SEAL KIT
|
CAS
AND O-RING REPAIR KIT Includes items in art marked with asterisk
|
