凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (9-48) - BALE THROWER HYDRAULIC CYLINDER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
793 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700711032
|
[1] |
CYLINDER ASSY.
|
L
HYDRAULIC CYLINDER COMPLETE
|
| 1. |
700704936
|
[1] |
SLEEVE CYLINDER
|
CAS
BARREL
|
| 2. |
700704938
|
[1] |
LOCK NUT
|
CAS
LOCKNUT
|
| 3. |
700704942
|
[1] |
PISTON
|
CAS
|
| 4. |
700704937
|
[1] |
ROD
|
CAS
- piston
|
| 5. |
700704939
|
[1] |
RETAINER
|
CAS
|
| 6. |
83-2254
|
[2] |
SET SCREW,Hex Soc, 1/4"-20 x 1/4"
|
CAS
1/4-20 X 1/4 CPHSSS
|
| 7. |
700704935
|
[1] |
BUSHING
|
CAS
BEARING
|
| 8. |
700704941
|
[1] |
SEAL KIT
|
CAS
AND O-RING REPAIR KIT Includes items in art marked with asterisk
|
