| 1. |
T27207
|
[2] |
FLANGED BEARING
|
CAS
FLANGE - bearing Superseded by part number: 617863R1
|
| 2. |
565672R92
|
[1] |
SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"
|
IH
BEARING - spherical Superseded by part number: 84330041
|
| 3. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 4. |
492-11038
|
[3] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 5. |
425-106
|
[3] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 6. |
7884950
|
[1] |
BOLT
|
CAS
7/16-14 X 2-1/8 C
|
| 7. |
429-107
|
[1] |
NUT,7/16"-14, G8
|
CAS
|
| 8. |
328-824
|
[3] |
BOLT,Hex, 1/2" - 20 x 1-1/2", Gr 8
|
CAS
|
| 9. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 10. |
700119299
|
[1] |
ARM
|
CAS
(Includes item 11)
|
| 11. |
7852718
|
[1] |
SLEEVE
|
CAS
- shear Superseded by part number: 196727
|
| 12. |
700119476
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 13. |
219-90
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
1/4-28 X 45 DEGREE ZERK Superseded by part number: 87569
|
| 14. |
700119301
|
[1] |
SPROCKET
|
CAS
ASSEMBLY - 44 tooth (Includes items 12 and 15)
|
| 15. |
700112222
|
[1] |
SLEEVE
|
CAS
- shear
|
| 16. |
700112234
|
[1] |
ANGLE
|
CAS
|
| 17. |
7770787
|
[1] |
FITTING,Sq Nk, 1/2" - 13 x 4", Gr 5, Full Thd
|
CAS
1/2-13 X 4 FTRHSNB
|
| 18. |
425-148
|
[1] |
JAM NUT,Jam, 1/2"-13, G5
|
CAS
Superseded by part number: 86632558
|
| 19. |
433-1044
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 3/4", Gr 5
|
CAS
5/8-11 X 2-3/4 RHSNB Superseded by part number: 9602228
|
| 20. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 21. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 22. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 23. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 24. |
396-21066
|
[3] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 25. |
629972R91
|
[1] |
DRIVE SPROCKET,15T
|
IH
SPROCKET - idler, 15 tooth Superseded by part number: 86619126
|
| 26. |
700709036
|
[1] |
LINK
|
L
- connector, high strength, #60 R/C with pins
|
| 27. |
700709038
|
[1] |
CHAIN
|
L
- roller, #60 high strength (10 foot bulk)
|
| 28. |
700119298
|
[1] |
SHIELD
|
CAS
- shaft
|
| 29. |
6521868
|
[1] |
BOLT
|
CAS
SHEAR BOLT KIT - packaged: (Includes 10 each of items 6 and 7) Superseded by part number: 226228
|
