凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (2-20) - PICKUP OVERRUNNING SLIP CLUTCH ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
976 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700119294
|
[1] |
SHAFT
|
CAS
- drive, pickup
|
| 2. |
126-147
|
[1] |
WOODRUFF KEY,#28, 5/16" x 2 1/8", HT
|
CAS
Superseded by part number: 88745
|
| 3. |
85-610
|
[2] |
SET SCREW,Sq Hd, 3/8"-16 x 5/8"
|
CAS
3/8-16 X 5/8 CPSQHSS Superseded by part number: 88144
|
| 4. |
700709001
|
[1] |
CLUTCH
|
CAS
ASSEMBLY (Includes items 8 thru 20) Superseded by part number: 700724786
|
| 5. |
700119295
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 60A16 tooth
|
| 6. |
413-516
|
[3] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 9635884, 72187198
|
| 7. |
492-11031
|
[3] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 8. |
700709148
|
[1] |
HUB
|
CAS
- overrunning (Includes item 14)
|
| 9. |
700709146
|
[1] |
LARGE PLATE
|
CAS
PLATE - drive, overrunning
|
| 10. |
700710520
|
[2] |
NIPPLE, LUBE
|
CAS
ZERK - special Superseded by part number: 84447449
|
| 11. |
700703410
|
[2] |
SEALING RING
|
CAS
RING - seal Superseded by part number: 428144
|
| 12. |
700703407
|
[2] |
SEALING RING
|
L
RING - thrust Superseded by part number: 86636027
|
| 13. |
700703404
|
[2] |
SNAP RING,M80, Int
|
CAS
RING - retainer Superseded by part number: 300633
|
| 14. |
700709149
|
[1] |
BUSHING
|
CAS
- bronze Superseded by part number: 279345
|
| 15. |
7814049
|
[6] |
SPRING
|
CAS
- compression
|
| 16. |
7814056
|
[6] |
PIN
|
CAS
|
| 17. |
700703406
|
[16] |
CAM
|
L
- ratchet Superseded by part number: 84819985
|
| 18. |
700703408
|
[16] |
SPRING
|
L
- outer Superseded by part number: 386510
|
| 19. |
700703409
|
[4] |
SPRING
|
CAS
- inner Superseded by part number: 386511
|
| 20. |
700709145
|
[1] |
HUB
|
CAS
- ratchet
|
