凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (3-12) - PICKUP LIFT ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
322 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
38-31016
|
[2] |
PIN,5/32" x 1", Coiled
|
CAS
Superseded by part number: 280634
|
| 2. |
6131916
|
[1] |
BUSHING
|
CAS
|
| 3. |
700119805
|
[1] |
ARM
|
CAS
- lift Superseded by part number: 700163045
|
| 4. |
413-840
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
|
CAS
.5 X 2.5 UNC GR5 YZD Superseded by part number: 87972
|
| 5. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 6. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 7. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 8. |
495-11081
|
[1] |
WASHER,3/4", SAE
|
CAS
Superseded by part number: 87381
|
| 9. |
700706024
|
[1] |
WASHER
|
CAS
SPACER
|
| 10. |
700119810
|
[1] |
CRANK
|
CAS
- pickup
|
| 11. |
700709466
|
[1] |
HANDLE
|
CAS
- crank
|
| 12. |
700709464
|
[1] |
NUT
|
CAS
3/8-16 NUT - push on
|
