纽荷兰零件查询(FD14E) - CRAWLER DOZER (1.2770[015]) - REAR TRANSMISSION-CONTROL VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
815 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79041977 | [1] | SPRING | LEC |
| 2. | 79034402 | [2] | HYD CONNECTOR | NHFITTING |
| 3. | 79089077 | [1] | BODY | LEC |
| 4. | 79028953 | [2] | SEAL,16.45mm ID x 25.55mm OD x 2.1mm Thk | LECPLUG |
| 5. | 79096127 | [2] | PLUG | LECFITTING |
| 6. | 79084957 | [2] | PLUG | LECFITTING |
| 7. | 10118740 | [4] | PLUG,M14 x 1.5 x 15, Brass | LEC |
| 8. | 79086322 | [2] | SEAL,22.7mm ID x 30mm OD x 2mm Thk | LECSEAL ASSY |
| 9. | 14455481 | [1] | O-RING,63.22mm ID x 1.78mm Width | LEC0-RING 1,78x63.22 Superseded by part number: 87016961 |
| 10. | 79056442 | [2] | SPRING | LEC |
| 11. | 79085683 | [2] | SPACER | LEC Superseded by part number: 76031332 |
| 12. | 14454181 | [2] | O-RING,28.3mm ID x 1.78" Width | LEC0-RING 1,78x28,30 |
| 13. | 79085680 | [2] | SPRING | LEC |
| 14. | 79056440 | [2] | RING | LEC |
| 15. | 79066940 | [2] | HYD CONNECTOR | LECFITTING - ASSEMBLY |
| 16. | 79056441 | [2] | PIN,12.98mm OD x 28mm L | LEC |
| 17. | 79096141 | [1] | RIGID TUBE | LECTUBE - RIGHT |
| 17. | 79096142 | [1] | RIGID TUBE | LECTUBE - LEFT |
| 18. | 79054398 | [4] | HYD CONNECTOR | LECFITTING |
| 19. | 14437885 | [1] | O-RING,13.30mm ID x 2.40mm | LEC13.3MM ID x 2.4 Thk |
