凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (30) - AUGER, LEFT AND DRIVE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
273 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7894975
|
[1] |
CLIP
|
CAS
|
| 2. |
7758212
|
[1] |
SPRING
|
CAS
- fastener
|
| 3. |
7894967
|
[1] |
HANDLE
|
CAS
- fastener
|
| 4. |
6474316
|
[1] |
PIN
|
CAS
- hinge
|
| 5. |
700108656
|
[1] |
SHIELD
|
HFI
- left
|
| 6. |
700108658
|
[2] |
SUPPORT
|
CAS
- hinge Superseded by part number: 700163299
|
| 7. |
700108649
|
[1] |
PANEL
|
HFI
SHIELD - drive, left Superseded by part number: 86637953, 145458, 700134917, 700131095, 280616
|
| 8. |
051417
|
[4] |
FLANGE - bearing
|
|
| 9. |
051292
|
[2] |
BEARING - spherical
|
|
| 10. |
061622
|
[1] |
GIB KEY
|
|
| 11. |
086439
|
[1] |
SPROCKET - auger drive
|
|
| 12. |
700108623
|
[1] |
AUGER
|
CAS
- left
|
| 13. |
714360
|
[2] |
FLANGED BEARING
|
IH
FLANGE - bearing
|
| 14. |
700704263
|
[1] |
SPHERICAL BEARING,55.562 mm ID x 100 mm OD x 48.4 mm
|
CAS
BEARING - spherical Superseded by part number: 76451
|
| . . |
068619
|
[4] |
1/2-13 X 1-1/4 RHSNB
|
|
| . . |
700047
|
[6] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| . . |
703132
|
[8] |
SERRATED SCREW
|
CAS
5/16-18 X 3/4 HFSS Superseded by part number: 145913
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
773184
|
[4] |
PISTON,Hex, 5/16" - 18 x 1/2", Gr 5
|
NNA
5/16-18 X 1/2 C Superseded by part number: 413-58
|
| . . |
705608
|
[1] |
WASHER,5/16", SAE
|
CAS
5/16 NP Superseded by part number: 495-11034
|
