凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (20) - PLUNGER ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
134 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108687
|
[1] |
ANGLE
|
CAS
|
| 2. |
700108509
|
[1] |
CRANK
|
CAS
ARM
|
| 3. |
8744047
|
[1] |
SEAL
|
CAS
- grease, inner
|
| 4. |
6855472
|
[1] |
BEARING HOUSING
|
CAS
- bearing
|
| 5. |
077016
|
[1] |
ZERK
|
|
| 6. |
8051005
|
[1] |
ROLLER BEARING,55mm ID x 100mm OD x 25mm W
|
CAS
BEARING - roller, cylindrical
|
| 7. |
8052326
|
[1] |
RING
|
CAS
- retainer Superseded by part number: 64417
|
| 8. |
8744054
|
[1] |
SEAL
|
CAS
- dust
|
| 9. |
700108510
|
[1] |
WASHER
|
CAS
WASHER - special
|
| 10. |
700107075
|
[1] |
BUSHING,16mm ID x 25.4mm OD x 27mm L
|
CAS
|
| 11. |
714360
|
[2] |
FLANGED BEARING
|
IH
FLANGE - bearing
|
| 12. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 13. |
700108511
|
[1] |
ARM
|
CAS
|
| 14. |
700108686
|
[1] |
ANGLE
|
CAS
|
| 15. |
700108685
|
[1] |
WEIGHT
|
CAS
- counterbalance
|
| . . |
7771017
|
[3] |
SPECIAL BOLT,5/8" - 11 x 6", Gr 5
|
HFI
5/8-11 X 6 C Superseded by part number: 88264
|
| . . |
7771363
|
[4] |
BOLT,Hex Flange, 1/2" - 13 x 1 1/4", SPL
|
CAS
1/2-13 X 1-1/4 HFSS Superseded by part number: 84209
|
| . . |
230-42110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
5/8-11 HCLN
|
