凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (21) - SLIP CLUTCH, PICKUP, DRIVE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
807 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
058107
|
[6] |
SPRING
|
|
| 2. |
392464
|
[1] |
LARGE PLATE
|
CAS
PLATE - pressure
|
| 3. |
027946
|
[2] |
DISC - clutch
|
|
| 4. |
700108665
|
[1] |
CLUTCH ASSEMBLY
|
CAS
(Includes bushing)
|
| 5. |
700108661
|
[1] |
PLATE
|
CAS
- clutch
|
| 6. |
700108671
|
[1] |
SHAFT
|
CAS
|
| 7. |
061622
|
[1] |
1/4 X 1/4 X 1-1/2 GIB KEY
|
|
| 8. |
852749
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| . . |
873174
|
[6] |
BOLT,Hex, 3/8" - 16 x 3 1/4", Gr 5
|
CAS
3/8-16 X 3-1/4 C
|
| . . |
704635
|
[6] |
NUT
|
CAS
3/8-16 HCLN Superseded by part number: 230-4216, 230-4216, 88902
|
