凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (32) - CHARGE AND STUFFER ASSMEBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
151 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108279
|
[1] |
COVER
|
CAS
PAN
|
| 2. |
700108284
|
[1] |
CURTAIN
|
CAS
WRAPPER - left
|
| 3. |
700108179
|
[2] |
CURTAIN
|
CAS
WRAPPER - center
|
| 4. |
700108287
|
[1] |
CURTAIN
|
CAS
WRAPPER - right
|
| 5. |
700108289
|
[1] |
CAM
|
CAS
TRACK Superseded by part number: 700157780
|
| 6. |
714360
|
[4] |
FLANGED BEARING
|
IH
FLANGE - bearing
|
| 7. |
700704263
|
[2] |
SPHERICAL BEARING,55.562 mm ID x 100 mm OD x 48.4 mm
|
CAS
BEARING - spherical Superseded by part number: 76451
|
| 8. |
700108675
|
[1] |
PLATE
|
HFI
|
| 9. |
700108180
|
[2] |
BAR
|
HFI
PLATE - stripper
|
| . . |
703983
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 C
|
| . . |
7701188
|
[5] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 C Superseded by part number: 87670
|
| . . |
703959
|
[5] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
|
CAS
1/2-13 X 1 C
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
068619
|
[4] |
1/2-13 X 1-1/4 RHSNB
|
|
| . . |
700054
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 X 1-1/4 RHSNB Superseded by part number: 86508773
|
| . . |
700047
|
[4] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| . . |
7703424
|
[4] |
FLANGE BOLT,Hex, Serr, 3/8" - 16 x 1"
|
CAS
3/8-16 X 1 HFSS Superseded by part number: 9706726
|
| . . |
7703432
|
[4] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HFSS Superseded by part number: 255918
|
