凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (34) - PLUNGER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
552 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108244
|
[1] |
SHAFT
|
CAS
- plunger
|
| 2. |
700108260
|
[2] |
ADJUSTING PLATE
|
CAS
SHIM
|
| 3. |
700108263
|
[3] |
ADJUSTING PLATE
|
CAS
SHIM
|
| 4. |
700108259
|
[4] |
ADJUSTING PLATE
|
CAS
SHIM
|
| 5. |
700108262
|
[6] |
ADJUSTING PLATE
|
CAS
SHIM
|
| 6. |
700703919
|
[1] |
KNIFE
|
CAS
- plunger, left
|
| 7. |
707455
|
[7] |
BOLT,#3, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 PB Superseded by part number: 419-3828
|
| 8. |
700703917
|
[1] |
KNIFE
|
CAS
- plunger, center
|
| 9. |
700703916
|
[1] |
KNIFE
|
CAS
- plunger
|
| 10. |
700702265
|
[4] |
HEX SOC SCREW,Flat Hd, 5/8"-11 x 1 3/4"
|
CAS
5/8-11 X 2 HSFHCHCS Superseded by part number: 164-83
|
| 11. |
700115416
|
[3] |
SHIM
|
CAS
.018 SHIM
|
| 12. |
700115417
|
[2] |
SHIM
|
CAS
.034 SHIM
|
| 13. |
700703920
|
[1] |
KNIFE
|
CAS
- plunger, right
|
| 14. |
052290
|
[4] |
NARROW RIM MACHINERY BUSHING
|
|
| 15. |
702852
|
[1] |
SPARE PART
|
HFI
1/2-13 X 2-3/4 HSHCS Superseded by part number: 61-35044, 61-35044, NLS
|
| 16. |
700707005
|
[1] |
FITTING
|
HFI
90 DEGREE ELBOW - male Superseded by part number: 222-1021
|
| 17. |
700707006
|
[1] |
LINE
|
CAS
- grease
|
| 18. |
700108249
|
[1] |
PITMAN
|
HFI
ASSEMBLY (Includes bushing)
|
| 19. |
700707397
|
[6] |
SPECIAL NUT
|
HFI
3/4-16 HFTLN Superseded by part number: 231-46112
|
| 20. |
7746167
|
[1] |
PLUG
|
HFI
CONNECTOR - female Superseded by part number: 222-1501
|
| 21. |
077115
|
[1] |
ZERK
|
|
| 22. |
7713829
|
[6] |
BEARING ASSY,19.56 mm ID x 63.75 mm OD
|
IH
- plunger Superseded by part number: 688282
|
| 23. |
700107895
|
[1] |
PLUNGER
|
HFI
Superseded by part number: 700120932
|
| 24. |
711770
|
[2] |
CAB
|
NNA
BEARING Superseded by part number: 667925R91
|
| 25. |
8052318
|
[2] |
RING, SNAP
|
CAS
RING - retainer, external Superseded by part number: 103-1162
|
| 26. |
700108245
|
[2] |
SUPPORT
|
CAS
|
| 27. |
700703740
|
[2] |
SEAL
|
CAS
- grease
|
| 28. |
700703921
|
[2] |
BUSHING,44.62mm ID x 49.33mm OD x 51.05mm L
|
CAS
BEARING - split
|
| 29. |
700108182
|
[4] |
SHIM
|
CAS
|
| 30. |
700108181
|
[2] |
ADJUSTING PLATE
|
CAS
SHIM
|
| 31. |
700115415
|
[2] |
SHIM
|
CAS
.010 SHIM
|
| 32. |
700115420
|
[4] |
SHIM
|
CAS
.034 SHIM
|
| 33. |
700115418
|
[4] |
SHIM
|
CAS
.010 SHIM
|
| 34. |
700115419
|
[6] |
SHIM
|
CAS
.018 SHIM
|
| . . |
700054
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 X 1-1/4 RHSNB Superseded by part number: 86508773
|
| . . |
704288
|
[8] |
LOCK NUT
|
CAS
1/2-13 HCLN Superseded by part number: 230-4218
|
