凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (37) - SHUTTLE FRAME AND NEEDLE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
734 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108176
|
[1] |
FRAME ASSY
|
HFI
FRAME - shuttle
|
| 2. |
7745003
|
[2] |
GUIDE
|
L
|
| 3. |
51200861
|
[2] |
U-BOLT
|
BRR
|
| 4. |
51200254
|
[4] |
WASHER
|
CAS
- special
|
| 5. |
700111996
|
[2] |
NEEDLE
|
CAS
|
| 6. |
077818
|
[2] |
ZERK
|
|
| 7. |
700705669
|
[4] |
BOLT,Hex, 1/2" - 13 x 4", Gr 8
|
CAS
1/2-13 X 4 C grade 8 Superseded by part number: 326-864
|
| . . |
230-4215
|
[4] |
NUT,5/16"-18, GA
|
CAS
5/16-18 HCLN
|
| . . |
231-5348
|
[4] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN grade G Superseded by part number: 86521610
|
