凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (50) - PLUNGER RAILS AND HAY DOG ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
950 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700108718
|
[2] |
SHIM
|
CAS
|
| 2. |
700707863
|
[5] |
SPRING
|
CAS
- torsion
|
| 3. |
700108719
|
[4] |
SHIM
|
CAS
|
| 4. |
700117281
|
[5] |
DRIVE DOG
|
CAS
DOG - hay
|
| 5. |
700108418
|
[5] |
WASHER
|
CAS
- special
|
| 6. |
700703778
|
[5] |
BUMPER
|
CAS
|
| 7. |
700108420
|
[3] |
RAIL
|
CAS
|
| 8. |
700108421
|
[1] |
RAIL
|
CAS
- hardened
|
| 9. |
703850
|
[4] |
HEX SOC SCREW,Flat Hd, 3/8"-16 x 1"
|
CAS
3/8-16 X 1 HSFCHCS Superseded by part number: 164-51
|
| 10. |
700108419
|
[2] |
RAIL
|
CAS
- lower
|
| 11. |
7883598
|
[2] |
HEX SOC SCREW,Flat Hd, CSK, 3/8" - 16 x 1 1/2"
|
CAS
3/8-16 X 1-1/2 HSFCHCS Superseded by part number: 164-53
|
| . . |
413-864
|
[5] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
CAS
1/2-13 X 4 C Superseded by part number: 86505993
|
| . . |
702035
|
[22] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| . . |
704858
|
[5] |
LOCK NUT
|
CAS
1/2-13 HTLN Superseded by part number: 230-4118
|
| . . |
873083
|
[2] |
SCREW
|
CAS
3/8-16 X 1-1/2 FTC
|
