凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (02-18) - PLUNGER ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
998 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-1096
|
[3] |
BOLT,Hex, 5/8" - 11 x 6", Gr 5
|
CAS
SCREW hex cap, 5/8-11 x 6 Superseded by part number: 88264
|
| 2. |
231-51410
|
[2] |
FLANGE NUT,Flg, USR, 5/8"-11
|
CAS
Superseded by part number: 86977731
|
| 3. |
700108687
|
[1] |
ANGLE
|
CAS
|
| 4. |
700108509
|
[1] |
CRANK
|
CAS
arm
|
| 5. |
8744047
|
[1] |
SEAL
|
CAS
grease, inner
|
| 6. |
6855472
|
[1] |
BEARING HOUSING
|
CAS
bearing
|
| 7. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 8. |
8051005
|
[1] |
ROLLER BEARING,55mm ID x 100mm OD x 25mm W
|
CAS
roller, cylindriclal
|
| 9. |
100-21393
|
[1] |
SNAP RING,3.938", Int, #393
|
CAS
Superseded by part number: 64417
|
| 10. |
8744054
|
[1] |
SEAL
|
CAS
dust
|
| 11. |
700108510
|
[1] |
WASHER
|
CAS
|
| 12. |
700107075
|
[1] |
BUSHING,16mm ID x 25.4mm OD x 27mm L
|
CAS
|
| 13. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8" bolt size Superseded by part number: 87613283
|
| 14. |
230-42110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
hex center lock, 5/8-11
|
| 15. |
714360
|
[2] |
FLANGED BEARING
|
IH
flange
|
| 16. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
spherical Superseded by part number: 47577203
|
| 17. |
700108511
|
[1] |
ARM
|
CAS
WA
|
| 18. |
700108686
|
[1] |
ANGLE
|
CAS
|
| 19. |
409-7820
|
[4] |
BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl
|
CAS
Superseded by part number: 84209
|
| 20. |
700108685
|
[1] |
WEIGHT
|
CAS
counter balance
|
