纽荷兰零件查询(FD14E) - CRAWLER DOZER (6.7120[003]) - ELECTRIC COMPONENTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
750 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79081900 | [1] | SENSOR | LECSWITCH, RESTRICTION |
| 2. | 79094547 | [1] | SWITCH | LEC Superseded by part number: 79065835 |
| 3. | 79069292 | [1] | IGNITION KEY | LECKEY |
| 4. | 79068180 | [1] | RESTRICTION SWITCH | LECSENSOR Superseded by part number: 71450991 |
| 5. | 10265060 | [1] | SEALING WASHER,32.4mm ID x 38mm OD x 1.5mm Thk | TORWASHER, COPPER, , Gasket M32.4 x 38 x 1.5 |
| 6. | 79065815 | [1] | SWITCH | LEC |
| 7. | 10257060 | [1] | SEALING WASHER,16.3mm ID x 22mm OD x 1.5mm Thk | BHBSEALING, M16.3 x 22 x 1.5, Copper Superseded by part number: 16508260 |
| 8. | 79086198 | [1] | PRESSURE SWITCH | LECSWITCH |
| 9. | 79093969 | [1] | BANJO BOLT | LECFILLER PLUG |
| 10. | 79086199 | [1] | SWITCH | LECC2708 |
| 11. | 10257460 | [1] | SEAL,M20.3 x 26 x 1.5 | MKTWASHER, SEALING, , Copper M20.3 x 26 x 1.5 Superseded by part number: 98429280 |
