凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (2-18) - GEARBOX AND CRANK ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
265 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700710391
|
[2] |
SHIM
|
CAS
- 0.64 / .025
|
| 2. |
700710390
|
[3] |
SHIM
|
CAS
- 0.25 / .010
|
| 3. |
700710393
|
[5] |
SHIM
|
CAS
- 1.27 / .050
|
| 4. |
700709989
|
[4] |
BOLT
|
CAS
3/4-10 X 10 B GR8 NP Superseded by part number: 426-12160
|
| 5. |
705566
|
[8] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 6. |
700123119
|
[2] |
SPACER
|
CAS
- BRG, CRANK ARM
|
| 7. |
700123122
|
[1] |
WASHER
|
CAS
- SPECIAL
|
| 8. |
703660
|
[1] |
BOLT,Hex 3/4" - 10 x 5", Gr 5
|
CAS
3/4-10 X 5 C Superseded by part number: 88421
|
| 9. |
700710072
|
[1] |
LOCK NUT
|
CAS
3/4-10 HTLN GR/C Superseded by part number: 280375
|
| 10. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 11. |
700123114
|
[2] |
ARM
|
CAS
WA - CRANK Superseded by part number: 700161319
|
| 12. |
700706799
|
[4] |
NUT
|
CAS
3/4-10 H GR8 Superseded by part number: 329-1012
|
| 13. |
704569
|
[4] |
NUT
|
CAS
3/4-10 HJN GR2 Superseded by part number: 86632557
|
| 14. |
700123044
|
[1] |
GEARBOX ASSY
|
CAS
GREABOX ASSEMBLY
|
