凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (2-22) - GEARBOX ASSEMBLY, CONTINUED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
364 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700710360
|
[2] |
SHIM
|
HFI
- LEFT, 0.51 / .020
|
| 2. |
700710359
|
[1] |
SHIM
|
CAS
- LEFT, 0.25 / 0.10
|
| 3. |
700710358
|
[1] |
SHIM
|
CAS
- LEFT, 0.13 / .005
|
| 4. |
7703275
|
[12] |
BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
CAS
M12 X 1.75 X 25 C Superseded by part number: 300388
|
| 5. |
700123102
|
[1] |
CAP
|
CAS
- LEFT
|
| 6. |
700710357
|
[2] |
SHIM
|
CAS
- LEFT, 0.08 / .003
|
| 7. |
700710353
|
[1] |
GEAR-SET
|
CAS
RING GEAR AND PINION
|
| 8. |
700710374
|
[1] |
CONE
|
CAS
- BEARING Superseded by part number: 924849C1
|
| 9. |
700710373
|
[1] |
CUP
|
CAS
- BEARING Superseded by part number: 924849C1
|
| 10. |
700710389
|
[2] |
SHIM
|
CAS
- PINION, INPUT 0.51 / .020
|
| 11. |
700710386
|
[2] |
SHIM
|
HFI
- PINION, INPUT 0.08 / .003
|
| 12. |
700710387
|
[1] |
SHIM
|
CAS
- PINION, INPUT 0.13 / .005
|
| 13. |
700710388
|
[1] |
SHIM
|
CAS
- PINION, INPUT 0.25 / .010
|
| 14. |
700710382
|
[2] |
SEAL
|
CAS
- OIL
|
| 15. |
700708350
|
[6] |
SCREW
|
CAS
M10 X 1.5 X 30 C Superseded by part number: 43140
|
| 16. |
700708367
|
[6] |
WASHER
|
HFI
10 L Superseded by part number: 140028
|
| 17. |
700123101
|
[1] |
CAP
|
CAS
- FRONT
|
| 18. |
700710371
|
[1] |
GASKET
|
CAS
- FRONT CAP
|
| 19. |
700710410
|
[1] |
NUT
|
CAS
- STAKE
|
| 20. |
700710383
|
[1] |
WASHER
|
CAS
- SPECIAL
|
| 21. |
700710379
|
[1] |
ROLLER BEARING,69.85 mm ID x 25.4 mm
|
CAS
CONE - BEARING Superseded by part number: ST2175
|
| 22. |
700710378
|
[1] |
BEARING, CUP
|
CAS
CUP - BEARING
|
| 23. |
700710375
|
[1] |
CUP
|
CAS
- BEARING Superseded by part number: A50529
|
| 24. |
700710364
|
[2] |
SHIM
|
CAS
- RIGHT 0.51 / .020
|
| 25. |
700710362
|
[1] |
SHIM
|
CAS
- RIGHT 0.13 / .005
|
| 26. |
700701720
|
[1] |
SEAL
|
CAS
- OIL
|
| 27. |
700123103
|
[1] |
CAP
|
CAS
- RIGHT
|
| 28. |
700710361
|
[2] |
SHIM
|
CAS
- RIGHT 0.08 / .003
|
| 29. |
700710363
|
[1] |
SHIM
|
CAS
SHIN - RIGHT 0.25 / .010
|
| 30. |
700710377
|
[1] |
CONE
|
CAS
- BEARING Superseded by part number: A50532
|
| 31. |
700710352
|
[1] |
PINION
|
CAS
|
| 32. |
700710380
|
[1] |
CONE
|
CAS
- BEARING Superseded by part number: 47941920
|
| 33. |
700710370
|
[1] |
CUP
|
CAS
- BEARING Superseded by part number: 47941920
|
