凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (2-24) - AUXILIARY DRIVE ASSEMBLY, LEFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
949 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51200277
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - IDLER
|
| 2. |
654438R91
|
[1] |
LINK
|
IH
- CONNECTOR, #80 R/C Superseded by part number: 241-1418
|
| 3. |
654437R91
|
[1] |
CHAIN (AG)
|
IH
CAHIN - ROLLER, #80 (10 FOOT BULK)
|
| 4. |
704130
|
[2] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| 5. |
700123337
|
[1] |
SPECIAL BOLT
|
CAS
DRAW BOLT WA
|
| 6. |
705582
|
[1] |
WASHER
|
CAS
5/8 Hardened Plain Washer Superseded by part number: 396-21066, 396-21066, NLS
|
| 7. |
7772122
|
[1] |
BOLT
|
CAS
3/4-10 X 3-1/2 C Superseded by part number: 326-1256
|
| 8. |
705111
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 9. |
704528
|
[1] |
NUT,3/4"-10, G5
|
CAS
3/4-10 H Superseded by part number: 280954
|
| 10. |
52183
|
[2] |
BUSHING
|
CAS
3/4 X 18 GAUGE NRMB Superseded by part number: Z52183
|
| 11. |
700123122
|
[1] |
WASHER
|
CAS
- SPECIAL
|
| 12. |
700123335
|
[1] |
BUSHING
|
CAS
|
| 13. |
6579106
|
[1] |
LARGE PLATE
|
CAS
CAP - PLATE Superseded by part number: 706579106
|
| 14. |
7883044
|
[1] |
BOLT,Hex 3/4" - 10 x 7", Gr 5
|
CAS
3/4-10 X 7 C Superseded by part number: 280316
|
| 15. |
700710072
|
[1] |
LOCK NUT
|
CAS
3/4-10 HTLN, GRADE C Superseded by part number: 280375
|
| 16. |
7701675
|
[6] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
CAS
1/2-13 X 2 C Superseded by part number: 9706716
|
| 17. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 18. |
704031
|
[6] |
NUT
|
NNA
1/2-13 H Superseded by part number: 425-108, 425-108, NLS
|
