日立零件查询（CHR70）PILOT PIPING (5-1) <MT> Hitachi HOP online
广数供应链运营团队, 15 02月, 2025，浏览：
655 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01. | 4202422 | [2] | ADAPTER;S | |
| 01A. | 4509180 | [1] | O-RING | |
| 02. | 4255305 | [2] | FITTING;PIPE | |
| 02A. | 4509180 | [1] | O-RING | |
| 03. | 4190244 | [3] | ELBOW;S | |
| 03A. | 4509180 | [1] | O-RING | |
| 05. | 4351261 | [1] | PIPE | |
| 06. | 4208913 | [1] | ELBOW;S | |
| 06A. | 4509180 | [1] | O-RING | |
| 10. | J011020 | [1] | BOLT;SEMS | |
| 10. | J271020 | [1] | BOLT;SEMS | TJ901020 |
| 10. | J271020 | [1] | BOLT;SEMS | TJ222010 |
| 17. | 4055312 | [12] | CLIP;BAND | |
| 21. | 4255792 | [2] | ADAPTER;S | |
| 21A. | 957366 | [1] | O-RING | |
| 25. | 4361042 | [1] | HOSE (C2) | |
| 26. | 4200465 | [2] | ADAPTER;S | |
| 26A. | 957366 | [1] | O-RING | |
| 27. | 4440104 | [1] | HOSE (C1) | |
| 29. | 4190292 | [1] | CLIP | |
| 31. | 4327293 | [4] | PROTECTOR | |
