日立零件查询（CHR70）PILOT PIPING (5-2) <MT> Hitachi HOP online
广数供应链运营团队, 15 02月, 2025，浏览：
979 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | 4325812 | [1] | VALVE;FC | |
| 01. | 4305337 | [2] | BOLT;SEMS | |
| 02. | 4364784 | [2] | TEE | |
| 02A. | 957366 | [1] | O-RING | |
| 03. | 4200466 | [4] | ADAPTER;S | |
| 03A. | 4509180 | [1] | O-RING | |
| 05. | 4380677 | [1] | SWITCH | |
| 05A. | 957366 | [1] | O-RING | |
| 06. | 4254563 | [1] | SWITCH;PRES. | |
| 06A. | 4113154 | [1] | O-RING | |
| 07. | 4332040 | [2] | SENSOR;PRES. | |
| 07A. | 957366 | [1] | O-RING | |
| 08. | 4174541 | [1] | PLUG | |
| 08A. | 4506418 | [1] | O-RING | |
| 09. | A852133 | [4] | ADAPTER;S | |
| 09A. | 4509180 | [1] | O-RING | |
| 11. | 4200469 | [1] | ADAPTER;S | |
| 11A. | 4506418 | [1] | O-RING | |
| 12. | 4353686 | [1] | SWITCH;PRES. | |
| 12A. | 957366 | [1] | O-RING | |
| 14. | J020820 | [2] | BOLT;SEMS | |
| 14. | J260820 | [2] | BOLT;SEMS | TJ900820 |
| 14. | J260820 | [2] | BOLT;SEMS | TA590108 |
| 15. | 4330230 | [1] | VALVE;SHUTTLE | |
| 16. | 4200466 | [3] | ADAPTER;S | |
| 16A. | 4509180 | [1] | O-RING | |
| 17. | 4154671 | [1] | ELBOW;S | |
| 17A. | 4509180 | [1] | O-RING | |
| 18. | 4092534 | [1] | PLUG | |
| 18A. | 4509180 | [1] | O-RING | |
| 19. | 4333040 | [1] | SWITCH | |
| 19A. | 957366 | [1] | O-RING | |
| 22. | 4440096 | [1] | HOSE;PLASTIC (9) | |
| 23. | 4440094 | [1] | HOSE;PLASTIC (10) | |
| 24. | 4440098 | [1] | HOSE;PLASTIC (11) | |
| 25. | 4440093 | [1] | HOSE;PLASTIC (12) | |
| 28. | 4156434 | [1] | ELBOW;S | |
| 28A. | 957366 | [1] | O-RING | |
| 29. | 4286916 | [1] | ELBOW;S | |
| 29A. | 957366 | [1] | O-RING | |
| 30. | 4440099 | [1] | HOSE;PLASTI (A1) | |
| 31. | 4440095 | [1] | HOSE;PLASTIC (B1) | |
