纽荷兰零件查询(FD14E) - CRAWLER DOZER (3.4400[001]) - LIFT CYLINDERS PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
319 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8292188 | [4] | CLAMP,Half | LECHALF FLANGE Superseded by part number: 86980728 |
| 2. | 11107534 | [1] | SCREW | LEC Superseded by part number: 11107531 |
| 3. | 11701721 | [1] | NUT,M10, Cl 10 | LEC10x1.5x8 Superseded by part number: 17038131 |
| 4. | 11106234 | [2] | BOLT,Hex, M10 x 1.5 x 25 mm, Cl 10.9, Full Thd | BURSCREW Superseded by part number: 11106231 |
| 5. | 14496631 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 6. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC8,15x17 Superseded by part number: 86624184 |
| 7. | 14420234 | [8] | SCREW,M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC10x1,25x30 Superseded by part number: 14420231 |
| 8. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 9. | 16044734 | [3] | BOLT,Hex, M8 x 1.25 x 75mm, Cl 10.9 | LEC Superseded by part number: Z1232960 |
| 10. | 79076680 | [1] | CLAMP | LECBLOCK |
| 11. | 79091154 | [2] | FLEXIBLE HOSE | LECHOSE ASSY |
| 12. | 79091328 | [3] | BRACKET | LEC |
| 13. | 79084667 | [1] | BRACKET | LEC |
| 14. | 79094539 | [1] | RIGID TUBE | LECTUBE |
| 15. | 79084665 | [1] | RIGID TUBE | LECTUBE |
| 16. | 79066946 | [2] | HYD CONNECTOR | LECFITTING - ASSEMBLY |
| 17. | 14437985 | [1] | O-RING,15.3mm ID x 2.4mm | LEC15.3MM ID x 2.4 Thk |
