纽荷兰零件查询(FD14E) - CRAWLER DOZER (93.4375[001]) - REAR EQUIPMENT CONTROL (May 14 2009 11:37AM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
436 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 15540631 | [2] | BOLT,Hex, M12 x 1.25 x 40mm, Cl 10.9, Full Thd | LEC12x1,25x40 |
| 2. | 11107431 | [1] | SCREW,Hex, M10 x 1.5 x 60mm, Cl 10.9 | LECHex, M10 x 60, 10.9 Superseded by part number: 86508619 |
| 3. | 79084821 | [2] | CLAMP | LECBLOCK |
| 4. | 12626231 | [2] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 5. | 11701721 | [1] | NUT,M10, Cl 10 | LEC10x1,5x8 Superseded by part number: 17038131 |
| 6. | 79080463 | [2] | FLEXIBLE HOSE | LECHOSE ASSY |
| 7. | 79080459 | [1] | RIGID TUBE | LECTUBE |
| 8. | 79080461 | [1] | RIGID TUBE | LECTUBE |
| 9. | 79087099 | [1] | BRACKET | LEC |
| 10. | 79066946 | [2] | HYD CONNECTOR | LECFITTING - ASSEMBLY |
| 11. | 14438185 | [1] | O-RING,24mm ID x 3mm | JES24MM ID x 3.0 Thk |
