凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (6-24) - TENSIONER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
747 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700123260
|
[1] |
ROD
|
CAS
|
| 2. |
62190
|
[4] |
PIN
|
CAS
5/32 X 1-1/2 COTTER PIN Superseded by part number: 88350
|
| 3. |
52258
|
[12] |
BUSHING
|
CAS
1 X 14 GAUGE NRMB
|
| 4. |
6280085
|
[3] |
BUSHING
|
CAS
SPACER Superseded by part number: 571823R1
|
| 5. |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
- EXTENSION
|
| 6. |
704247
|
[12] |
NUT
|
CAS
3/8-16 HFSLN GR/F Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 7. |
700123254
|
[1] |
SUPPORT
|
CAS
WA
|
| 8. |
702400048
|
[4] |
ROD
|
CAS
Superseded by part number: 700602446
|
| 9. |
7703432
|
[4] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HFSS Superseded by part number: 255918
|
