纽荷兰零件查询(FD14E) - CRAWLER DOZER (94.5220[004]) - RIPPER (PD)-LIFT CYLINDERS PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
625 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79093022 | [2] | CYLINDER | LEC- ASSEMBLY SEE TAV.5 |
| 2. | 11112234 | [4] | BOLT,Hex, M12 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11112231 |
| 3. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 4. | 14496731 | [4] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 5. | 79078115 | [1] | RIGID TUBE | LECTUBE - REAR LEFT |
| 5. | 79078127 | [1] | RIGID TUBE | LECTUBE - REAR RIGHT |
| 6. | 79078133 | [1] | RIGID TUBE | LECTUBE - FRONT RIGHT |
| 6. | 79078136 | [1] | RIGID TUBE | LECTUBE - FRONT LEFT |
| 7. | 79078157 | [1] | RIGID TUBE | LECPIPING |
| 8. | 79078868 | [2] | FLEXIBLE HOSE | LECHOSE ASSY |
| 9. | 79078869 | [2] | FLEXIBLE HOSE | LECHOSE ASSY |
| 10. | 11106234 | [2] | BOLT,Hex, M10 x 1.5 x 25 mm, Cl 10.9, Full Thd | BURSCREW Superseded by part number: 11106231 |
