纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6545[002]) - FORESTRY PROTECTIONS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
157 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79088451 | [1] | GUARD | LECREAR SCREEN |
| 2. | 79088503 | [1] | GUARD | LECSWEEPS |
| 3. | 79088485 | [1] | SUPPORT | LEC- SIDE LEFT |
| 3. | 79088534 | [1] | SUPPORT | LEC- SIDE RIGHT |
| 4. | 79087180 | [2] | PIN | LEC |
| 5. | 8285380 | [2] | PLATE | LEC |
| 6. | 16043634 | [4] | SCREW,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd | LECBOLT, Hex, M8 x 25, 10.9, Full Thd Superseded by part number: 16043637 |
| 7. | 10615679 | [4] | LOCK WASHER,Ext Tooth, M8 | BHBWASHER Superseded by part number: 10615671 |
| 8. | 11113034 | [4] | SCREW | TOR12x1,75x45 Superseded by part number: 11113031 |
| 9. | 79005242 | [22] | WASHER,12.6mm ID x 28mm OD x 7mm Thk | LEC |
| 10. | 10615879 | [8] | LOCK WASHER,Serr, M12 | LECWASHER, LOCK, Serr, M12 Superseded by part number: 10615870 |
| 11. | 11112434 | [4] | BOLT,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11112431 |
| 12. | 11112634 | [14] | SCREW | IMO12x1,75x35 Superseded by part number: 626-12035 |
| 13. | 12577521 | [14] | NUT,M12 x 1.75 | LECNUT, LOCK, M12 x 1.75 |
