纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.043[02]) - CRANKCASE COVERS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
580 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 98415388 | [1] | BOX | LEC |
| 2. | 8818504 | [1] | COVER | MOD- INSPECTION |
| 3. | 98411989 | [1] | GASKET,0.8mm Thk | TOR |
| 4. | 4801846 | [1] | BUSHING | LEC125X131X28 |
| 5. | 14326311 | [1] | MAGNETIC PLUG | LECPLUG, MAGNETIC - IN ALTERNATIVE 28X1,5X22 Superseded by part number: 14326340 |
| 5. | 14326340 | [1] | PLUG | MKT- IN ALTERNATIVE 28X1,5X22 |
| 6. | 17300081 | [1] | O-RING | LEC |
| 7. | 10902124 | [2] | SCREW,Hex, M6 x 14mm, Cl 8.8 | TTF |
| 8. | 11197774 | [2] | BELLEVILLE WASHER,Belleville, M6.4 | TTF |
| 9. | 40101384 | [1] | SEAL,131mm ID x 158mm OD x 23mm Thk | TOR131X150X23 |
| 11. | 61583713 | [1] | PLATE | ZED |
| 12. | 99445563 | [1] | GASKET,0.8mm Thk | BRE Superseded by part number: |
| 13. | 11190574 | [4] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 14. | 15970724 | [4] | SCREW,Hex, M10 x 1.25 x 25mm, Cl 8.8, Full Thd | TTF |
| 15. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
| 10. | 14274631 | [8] | LOCK BOLT,Hex, M12 x 1.25 x 35mm, Cl 10.9 | TTF |
