纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.045[01]) - BREATHER - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
337 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 99451886 | [1] | RIGID TUBE | LEC |
| 2. | 14465381 | [1] | O-RING,3.109" ID x 3.387" OD x 0.139" | MKT3,53X29,74 Superseded by part number: 17290781 |
| 4. | 11193874 | [1] | BELLEVILLE WASHER,8.4mm ID x 16.00mm OD x 1.4mm, 1.85mm, Cl 8.8 | TTF |
| 6. | 11190574 | [1] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 7. | 98445136 | [1] | COVER | BRE |
| 8. | 17285481 | [1] | GASKET,0.103" Thk x 2.987" ID, -151 | LEC2,62X75,87 Superseded by part number: 2854075 |
| 9. | 10901921 | [1] | BOLT,Hex, M6 x 70mm, Cl 8.8 | MKT6X70 Superseded by part number: 14303930 |
| 10. | 14496404 | [5] | WASHER,M6 x 12 x 2 Thk | TTF Superseded by part number: 17094724 |
| 11. | 98445561 | [1] | FILTER | BRE |
| 12. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
| 12. | 1940149 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 5. | 15970324 | [1] | SCREW,Hex, M10 x 1.25 x 16mm, Cl 8.8, Full Thd | TTF |
| 9. | 10902624 | [4] | SCREW,Hex, M6 x 25mm, Cl 8.8, Full Thd | TTF Superseded by part number: 10902621 |
| 3. | 16043224 | [1] | BOLT,Hex, M8 x 16mm, Cl 8.8 | NH |
