纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.060[02]) - CYLINDER HEAD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
991 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 98450581 | [12] | CUP | LEC- UPPER |
| 2. | 98450393 | [12] | SPRING | BRE |
| 3. | 61577212 | [12] | SPACER | LEC |
| 4. | 61577211 | [24] | ROCKER ARM COTTER | LEC7,85X10 Superseded by part number: 61320851 |
| 5. | 4851896 | [6] | SUPPORT | BRE |
| 6. | 98480252 | [2] | SHAFT | BRE- ASSY |
| 7. | 14328501 | [2] | PLUG,M16, Tapered | TOR |
| 8. | 61316052 | [12] | FLANGE COVER CAP | LEC |
| 9. | 98448462 | [6] | STD INLET VALVE | LECSTD ENGINE INLET VALVE Superseded by part number: 2997553 |
| 10. | 4860107 | [6] | STD EXHAUST VALVE | LECSTD ENGINE EXHAUST VALVE |
| 11. | 40102060 | [6] | GASKET | LEC Superseded by part number: 4861823 |
| 12. | 98479642 | [12] | ROCKER ARM | BRE |
| 13. | 4786841 | [12] | SCREW | MOD |
| 14. | 61584377 | [12] | NUT | MOD |
| 15. | 61577214 | [4] | SPRING | LEC |
| 16. | 61577283 | [4] | SCREW | LEC |
| 17. | 10520004 | [6] | WASHER,12.2mm ID x 22mm OD x 3mm Thk | TTF Superseded by part number: 10520021 |
| 18. | 16101521 | [6] | NUT,M12 x 1.25, Cl 10 | ZED Superseded by part number: |
| 19. | 11067276 | [4] | SNAP RING,M24, Ext | JES |
| 20. | 1940149 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 20. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
